FastHall measurement capability contained in a complete characterization platform

The MeasureReady™ M91 FastHall™ measurement controller is a revolutionary, all-in-one Hall analysis instrument that delivers significantly higher levels of precision, speed, and convenience to researchers involved in the study of electronic materials.

And now this novel capability is available as part of the FastHall Station, an integrated, high-precision tabletop measurement system for simplified Hall measurements and less experimental setup.

The FastHall Station includes a Windows® 10 PC, 1 T permanent magnet, high precision sample holder, and all the necessary software and cabling to provide a range of measurement capabilities, including sample resistances up to 1 GΩ and mobility measurements down to 0.01 cm²/V ‍s ­— making it a great choice for labs studying low-mobility materials.

		Widest measurement range Proprietary FastHall™ technology enables low-mobility measurements without field reversal in seconds Mobility measurements down to 0.01 cm2/V ‍s for van der Pauw samples with resistances from 10 mΩ to 1 GΩ Completely guarded triaxial cabling to fully shielded, insertable, light-tight sample chamber plus an LN2 option
		Completely integrated mini-system solution MeasureLINK™-MCS software provides standard sequences, charts, exportable reports, and user-customizable test scripts M91 FastHall™ instrument with high resistance option integrates all signal source, measure, and switching functions Easy-to-use spring pin and solder sample holder cards accommodate up to 10 mm × 10 mm van der Pauw and Hall bar type samples
		Increased productivity and flexibility Measurement times greatly reduced through patented FastHall™ method and fully integrated system solution Available gate bias instrument option and ability to easily integrate third-party sources and instruments Simple, repeatable, and reversible permanent magnet with nominal fields of 1 T and optional 0.75 T for LN2 chamber

Watch the demo video:

ORDER NOW

A new approach to Hall measurement

The MeasureReady M91 is a revolutionary, all‑in-one Hall analysis instrument that delivers significantly higher levels of precision, speed, and convenience to researchers involved in the study of electronic materials.

Featuring Lake Shore’s patented* new FastHall measurement technique, the M91 fundamentally changes the way the Hall effect is measured by eliminating the need to switch the polarity of the applied magnetic field during the measurement. This breakthrough results in faster and more accurate measurements, especially when using high-field superconducting magnets or when measuring very low-mobility materials.

*Protected by US patent number 9797965. Other patents pending.

		Simpler and more convenient All-in-one instrument Automatically selects optimal excitation and measurement levels Automatically executes measurement steps Provides complete Hall analysis Easy to use, easy to integrate with existing lab systems
		Makes better measurements, faster No need to reverse the magnetic field with FastHall Up to 100× faster for low-mobility materials Improves accuracy by minimizing thermal drift
		Cost-effective Build a new Hall system or upgrade an existing one Add state-of-the-art Hall measurement capability to any lab Use with any type of magnet

8400 Series features

• Ideal for variable temperature measurement and mobilities from 1 to 10⁶ cm²/V ‍s
• Optional AC field extends mobility measurement range down to 10^-3 cm²/V ‍s
• Maximum DC fields to 1.67 T (8404) and 2.25 T (8407)
• Optional AC fields to 1.18 T (8404) and 1.31 T (8407)
• Standard resistance range of 0.5 mΩ to 10 MΩ
• High resistance option widens range to 200 GΩ
• Low resistance option significantly reduces resistance noise floor
• Temperatures from 15 K to 1273 K
• Also available as an option for the CRX-VF cryogenic probe station
